PDLC Laminated Smart Glass is a premium architectural safety solution that merges intelligent electrochromic control with structural integrity. Engineered using high-pressure autoclave lamination, it sandwiches professional-grade PDLC film between fully tempered float glass layers — delivering instant, one-key privacy switching (transparent ↔ milky opaque) while meeting stringent building safety standards.
Designed for global B2B architects, interior designers, and façade engineers, this product eliminates compromise: no trade-off between aesthetics, acoustic performance, UV protection, or long-term reliability. Its 48V/60V low-voltage AC drive ensures field-safe installation and compliance with international electrical codes — enabling direct integration into commercial and residential smart building ecosystems.
Certified laminated safety glass (EN 12600 P2A). Shatter-resistant: fragments bond to interlayer film upon impact — zero splash risk. Explosion-proof & impact-resistant for high-traffic commercial interiors.
True one-button operation: power ON = transparent; power OFF = uniform milky opacity. No residual image, no flicker. Seamless daylight management + instant privacy — ideal for offices, bathrooms, and healthcare spaces.
Autoclave-laminated under constant 130°C & ≥1.3MPa pressure — eliminating bubbles, delamination, and edge defects. Factory-wired electrodes, IP65-rated terminals, and 10–15 year service life.
Dynamic meeting rooms, executive suites, open-plan zones — switch privacy on demand without blinds or curtains.
Hotel bathroom shower walls, luxury suite dividers, spa partitions — combine elegance, hygiene, and instant privacy.
Curtain walls, elevator cabs, villa windows — enhance energy efficiency (UV blocking), reduce glare, and elevate design language.
High-definition rear-projection screens for museums, conference halls, and retail displays — crisp image quality in both states.
| Parameter | Specification |
|---|---|
| Driving Voltage | 48V / 60V AC (safe extra-low voltage, SELV) |
| Light Transmittance (ON) | 84–91% (selectable grades: 84–85%, 87–88%, 90–91%) |
| Haze Rate (ON/OFF) | ≤6% (transparent) / 99.8% (opaque) |
| Response Time | ≤0.3 seconds (full switch) |
| Operating Temperature | −20°C to +60°C |
| Standard Thickness | 5+5mm, 6+6mm, 8+8mm, 10+10mm tempered glass |
| Max Custom Size | 2000 × 3000 mm (flat or curved) |
| Lamination Process | High-pressure autoclave (≥1.3 MPa, 130°C, ≥60 min) |
Yes. This falls under IEC 61140’s Safety Extra-Low Voltage (SELV) classification — requiring no additional insulation barriers. It complies with NEC Article 411 and EU Low Voltage Directive 2014/35/EU, enabling safe installation in wet locations (e.g., bathrooms) and compatibility with standard building automation systems.
Autoclave lamination applies uniform heat and pressure across the entire surface — eliminating micro-bubbles, ensuring perfect interlayer adhesion, and preventing edge delamination. Unlike vacuum or EVA methods, this achieves zero optical distortion and >10-year stability under thermal cycling and UV exposure.
Absolutely. We support custom curvature (radius ≥600mm), CNC-polished edges (bevel, flat, pencil), custom transmittance grading, and tailored electrode routing — all engineered and validated pre-lamination. Lead time adjusts per complexity; engineering consultation is included at no cost.
Access full technical documentation, CAD/BIM files, and dedicated engineering support — all backed by ISO 9001-certified manufacturing and 10-year performance warranty.
