The P10 self-adhesive flexible transparent LED film redefines architectural display integration — engineered specifically for commercial glass curtain walls, retail façades, and high-end exhibition spaces. Unlike rigid LED panels or opaque digital signage, this ultra-thin (3mm) film delivers true 92%+ light transmittance, preserving daylight clarity and building aesthetics when powered off. Its self-adhesive backing enables direct, bracket-free installation on glass, acrylic, and other smooth transparent substrates — reducing structural load (≤5.5kg/㎡) and cutting installation time by up to 70%. Optimized for long-distance visibility (10–250m), it renders crisp, flicker-free 3D holographic content with industry-leading brightness (1500–5000 cd/㎡) and a wide 120° horizontal viewing angle.
Only 3mm thick with 92%+ visible light transmittance. Maintains unobstructed building views and natural illumination — no visual compromise when idle.
Pre-applied industrial-grade adhesive backing allows direct pasting onto clean glass/acrylic surfaces. No brackets, frames, or structural reinforcement needed — supports arbitrary cutting and gentle bending.
Engineered for large-scale visibility: 10.4mm pixel pitch, 9216 pixels/m², and ≥1920Hz refresh rate ensure sharp, smooth, flicker-free 3D holograms from 10m to 250m.
Transform high-rise façades into dynamic brand canvases — seamless integration with structural glass systems.
Engage pedestrians with immersive 3D holograms in shopping malls, flagship stores, and luxury boutiques.
Create lightweight, reconfigurable holographic backdrops for trade shows, museums, and pop-up installations.
| Parameter | Value |
|---|---|
| Pixel Pitch | 10.4 mm × 10.4 mm |
| Pixel Density | 9,216 dots/m² |
| Module Size | 1500 mm × 250 mm |
| Panel Thickness | 3 mm |
| Weight | ≤ 5.5 kg/m² |
| Light Transmittance | ≥ 92% |
| Brightness Range | 1500 – 5000 cd/m² (adjustable) |
| Viewing Angle | H: 120° / V: 100° |
| Refresh Rate | ≥ 1920 Hz / ≥ 3840 Hz (optional) |
| Operating Temp. | –10°C to +45°C |
| Storage Temp. | –40°C to +85°C |
| IP Rating | IP30 (indoor use) |
| Power Supply | 220V ±10%, 50Hz AC |
| Power Consumption | 240 W/m² (typ.), 800 W/m² (peak) |
Yes. The film is highly flexible and supports gentle bending (minimum radius ≥ 500mm). For complex curves, we recommend professional on-site assessment and custom module segmentation.
No. It operates on standard 220V AC power and uses industry-standard HUB75 interface. Our dedicated control system supports HDMI/SDI input and remote cloud management via Ethernet/WiFi.
Each module features modular design with front-accessible connectors and hot-swappable driver ICs. Routine diagnostics and firmware updates are fully remote-enabled.
We provide a 3-year limited warranty covering materials and workmanship, plus lifetime technical consultation and on-demand firmware upgrades for registered users.
Get a tailored solution proposal, sample kit, and installation guidance — all within 48 business hours.
